Foam Solution Supplier


Foam Solution



  AFFF AR - AFFF
About Aqueous Film Forming Foam concentrate, produces thin, yet strong film on the surface of hydrocarbon fuels thereby sealing the fuel surface and preventing fuel vapour release. Due to presence of Fluorocarbon surfactant the spreading characteristic of the foam is such that a positive, fast spreading coverage action takes over the fuel surface, resulting fast extinguishment. The synthetic base imparts good shelf life of the concentrate free from settling ingredients and bad odour. It is available in 3% & 6% concentrate. ALCOHOL TYPE FOAM CONCENTRATE (ATC) AR-AFFF is a foam concentrate containing polysaccharide, which forms a pseudo plastic film on the surface of the polar solvents. AR-AFFF forms a cohesive thin polymeric film at the interface between foam and the water soluble Polar solvents. This thin polysaccharide film protects the foam without destruction of aqueous film by polar solvents. The polymeric film has self-sealing characteristics whereby the film, if disturbed gets regenerated by itself. AR-AFFF forms an aqueous film like AFFF on surface of hydrocarbon solvents. AR-AFFF is also known as ARC (Alcohol Resistant Concentrate), ATC (Alcohol Type Concentrate), AGFFF (Aqueous Gel Film Forming Foam), MPF (Multipurpose Foam) or UF (Universal Foam).
Application It can be used with fresh water as well as seawater. It can be used with fresh water as well as seawater.
  It is suitable for application with standard low expansion foam generating equipment, both aspirating and non-aspirating type. An ideal choice as a rapid effective extinguishing agent for fighting fires particularly of high risk areas like aviation, petrochemical complexes, refineries and tank terminals.
  It can be used in fixed sprinkler system for protection against risks of flammable liquids. The high foaming characteristics, fast spreading combined with film forming ability makes it an ideal choice as for rapid extinguishment and fast coverage.
PROPERTY 3%

6%

3 X 3 % 3 X 6 %
APPEARANCE Amber coloured liquid Amber coloured liquid Amber coloured viscous liquid Amber coloured viscous liquid
pH @20 °C 6.5 - 8.5 6.5 - 8.5 6.5 - 8.5 6.5 - 8.5
Sp. Gravity @20 °C 1.00 to 1.03 1.00 to 1.03 1.00 to 1.03 1.00 to 1.03
Freezing Point 0 °C 0 °C 1.7 °C 1.7 °C
Viscosity @20 °C Less than 5 cSt Less than 5 cSt Non Newtonian fluid* Non Newtonian fluid*
Sediment Maximum 0.25% Maximum 0.25% Maximum 0.25% Maximum 0.25%
*Expansion Ratio > 7 : 1 > 7 : 1 > 7 : 1 > 7 : 1
*Drainage (25 %) > 2 min > 2 min > 7 min > 7 min
